ALL IN. ALL OUT
Your ace up the jersey sleeve! With the MACINA PROWLER carbon frame the KTM engineering team has gone "all in". The Exonic model is one of those products that can only be described in superlatives. It has been developed for the fight on the racetrack and extreme terrain as well as boundless riding pleasure when every millisecond counts.
STRAIGHT-LINE-LINK (SLL)
Thanks to the proven STRAIGHT-LINE-LINK (SLL) concept for a sensitive and direct suspension performance, 180mm travel at the fork and 170mm at the rear, the PROWLER's field of application is on demanding enduro trails.
Dimension-Mix (DiMMiX)
The Dimension-Mix (DiMMiX) provides a decisive advantage in difficult situations: 29-inch wheel at the front for optimal riding stability paired with the 27.5-inch PLUS tire at the rear for best power transmission and traction.
BOSCH PERFORMANCE LINE CX RACE
The new Bosch Performance Line CX Race is only available on a few selected models across the world, it's lighter and provides 60% more support compared to its counterpart, the CX Gen 4. It's easily configured and tuned to your liking through the Bosch Flow app.
KEY FEATURES
DRIVE UNIT Bosch Performance Line CX-Race 85NM (SMART SYSTEM)
BATTERY Bosch PowerTube 750WH (SMART SYSTEM)
DISPLAY Bosch Kiox 300 TFT & Bosch LED Remote (SMART SYSTEM)
CHARGER Bosch STANDARD Charger 4A (SMART SYSTEM)
BOSCH CONNECT MODULE: Bosch Smart System ConnectModule eBike Alarm installed
SPECIFICATIONS
- FRAME
Macina Prowler Dimmix Perf. Carbon SLL-LTE 170mm UDH - FORK
FOX 38 Factory FLOAT FIT4 Kashima 180 mm - SHOCK
FOX DHX2 Factory 250x75, 170 mm - SEATPOST
RockShox Reverb AXS, 150 mm - BRAKES
MAGURA MT7 HC3, 4 Piston - ROTOR
Front: Magura MDR-P CL, 203 mm
Rear: Magura MDR-P CL, 180 mm - DERAILLEUR
SRAM AXS Eagle XX1, 12-Speed - CASSETTE
SRAM XX Eagle T-Type XS-1297 / 10-52T - CHAIN
SRAM XX Eagle T-Type 12s - SHIFTER
SRAM AXS Pod Ultimate Controller
- CHAIN RING
SRAM XX Eagle Transmission, 36T, Direct Mount - WHEELS
Front: DT Swiss HXC 1501 SPLINE 29 CL 110/15TA / 622x30TSS
Rear: DT Swiss HXC 1501 SPLINE 27 CL 148/12TA / 584x35TSS - TYRES
Front: Schwalbe Eddy Current,Evo SuperTrail, TLE, 27.5 x 2.8
Rear: Schwalbe Eddy Current, Evo SuperGravity,TLE, 29 x 2.6 - HANDLEBAR
KTM Prime Trail35, Carbon rizer20, 800mm - STEM
KTM TEAM II Trail 35, 50 mm - HEADSET
Acros AICR internal 1.1/8"-1.5" angle limit - CRANKSET
FSA CK-702/IS Carbon 160mm - GRIPS
Ergon GA20 - SADDLE
Selle San Marco GND, Open Fit, Supercomfort - BOSCH POWERMORE COMPATIBLE
NO
* Subject to technical modification without notice. Errors and omissions excepted.
